| Nominal Diameter | 6,5''- 165 mm |
| Rated Impedance | 4 Ohm |
| Nominal Power Handling 1 | 220 W |
| Program Power 2 | 450 W |
| Sensitivity 3 | 94 dB (2,83V/1m) |
| Frequency Range 4 | 70-4000 Hz |
| Minimum Impendance | - |
| Basket Material | Aluminum |
| Magnet Material | Neodymium |
| Cone Material | Doped cellulose fiber |
| Cone Shape | Exponential |
| Surround | Nomex Fabric |
| Suspension | Nomex Fabric |
| Voice Coil Diameter | 2 in - 50 mm |
| Voice Coil Winding Material | Copper |
| Voice Coil Length | 12,5 mm - 0,49 in |
| Voice Coil Former Material | Kapton |
| Connection Type | - |
| Ferrofluid | No |
| Magnet Gap Height | 8 mm - 0,31 in |
| Max. Peak to Peak Excursion Xlim | - |
| Efficiency Bandwidth Product EBP | 162 |
| Recommended Loading |
Vented Box |
| Resonance Frequency | 73 Hz |
| DC Resistance | 2,9 Ohm |
| Mechanical Q Factor | 4 |
| Electrical Q Factor | 0.45 |
| Total Q Factor | 0.41 |
| BI Factor | 7,8 Tm |
| Effective Moving Mass | 20 g |
| Equivalent Cas air Loaded | 6 lt (dm³) - 0,21 cuft |
| Suspension Compliance | - |
| Effective Piston Diameter | 132 mm - 5,2 in |
| Effective Piston Area | 137 cm² - 21,24 sq in |
| Max. Linear Excursion 5 | 4,5 mm - 0,18 in |
| Voice Coil Inductance @ 1kHz | 0,33 mH |
| Half.space Efficiency |
0,6 % |
| Overall Diameter | 165 mm - 6,5 in |
| Baffle Cutout Diameter | 145 mm - 5,71 in |
| Flange and Gasket Thickness | 2,5 mm - 0,1 in |
| Total Depth | 74,5 mm - 2,93 in |
| Bolt Circle Diameter | 154,5 mm - 6,08 in |
| Bolt Holes Quantity and Diameter | 4 / 5 mm - 0,2 in |
| Net Weight | 1,3 Kg - 2,86 lb |
| Shipping | This item ships to |
| Delivery | Estimated between and . Will usually ship within 1-3 businesses day. |
Description
| Nominal Diameter | 6,5''- 165 mm |
| Rated Impedance | 4 Ohm |
| Nominal Power Handling 1 | 220 W |
| Program Power 2 | 450 W |
| Sensitivity 3 | 94 dB (2,83V/1m) |
| Frequency Range 4 | 70-4000 Hz |
| Minimum Impendance | - |
| Basket Material | Aluminum |
| Magnet Material | Neodymium |
| Cone Material | Doped cellulose fiber |
| Cone Shape | Exponential |
| Surround | Nomex Fabric |
| Suspension | Nomex Fabric |
| Voice Coil Diameter | 2 in - 50 mm |
| Voice Coil Winding Material | Copper |
| Voice Coil Length | 12,5 mm - 0,49 in |
| Voice Coil Former Material | Kapton |
| Connection Type | - |
| Ferrofluid | No |
| Magnet Gap Height | 8 mm - 0,31 in |
| Max. Peak to Peak Excursion Xlim | - |
| Efficiency Bandwidth Product EBP | 162 |
| Recommended Loading |
Vented Box |
| Resonance Frequency | 73 Hz |
| DC Resistance | 2,9 Ohm |
| Mechanical Q Factor | 4 |
| Electrical Q Factor | 0.45 |
| Total Q Factor | 0.41 |
| BI Factor | 7,8 Tm |
| Effective Moving Mass | 20 g |
| Equivalent Cas air Loaded | 6 lt (dm³) - 0,21 cuft |
| Suspension Compliance | - |
| Effective Piston Diameter | 132 mm - 5,2 in |
| Effective Piston Area | 137 cm² - 21,24 sq in |
| Max. Linear Excursion 5 | 4,5 mm - 0,18 in |
| Voice Coil Inductance @ 1kHz | 0,33 mH |
| Half.space Efficiency |
0,6 % |
| Overall Diameter | 165 mm - 6,5 in |
| Baffle Cutout Diameter | 145 mm - 5,71 in |
| Flange and Gasket Thickness | 2,5 mm - 0,1 in |
| Total Depth | 74,5 mm - 2,93 in |
| Bolt Circle Diameter | 154,5 mm - 6,08 in |
| Bolt Holes Quantity and Diameter | 4 / 5 mm - 0,2 in |
| Net Weight | 1,3 Kg - 2,86 lb |
Shipping
| Shipping | This item ships to |
| Delivery | Estimated between and . Will usually ship within 1-3 businesses day. |
